Shopping Center Porte di Catania

Centro Commerciale Porte di Catania

SURFACE SALE COVERED PARKING
LOT 1 61.703,8 MQ 24.302,4 MQ
LOT 2A 13.996,6 MQ 5.292,5 MQ
LOT 2B 14.181,6 MQ 14.181,6 MQ
LOT 3 32.912 MQ
LOT 4 37.249,8 MQ
TOTAL 89.882 MQ 113.938 MQ



  • MC concrete structural 24.350
  • MC concrete for caldane 16,275



CONSTRUCTION SYSTEM

The Mall “Porte di Catania” consists of a multi-storey building built in 4 batches
each comprise more bodies spliced together.

Structural features:

Centro Commerciale Porte di CataniaFIRST FLOOR PLAN LOT 1

Lot 1:

  • 2 floors above ground;
  • Section 70×70 and 70×60 cm pillars (tapered);
  • Mesh pillars 16,00×8,00 m and 16,00×16,00 m;
  • First deck slab formed by tiled vigor 50 cm beams and cross beams at overturns;
  • Attic roof tiles formed by TTL 50 cm beams to cross;
  • Overall height of deck varies from 5.60 to 5.80 m for the inter-slab and 5.50 to 6.14 m for the deck covering.

Centro Commerciale Porte di CataniaSECTIONS LOT 1

Lot 2A:

  • 2 floors above ground;
  • Section 70×70 and 70×60 cm pillars (tapered);
  • Mesh pillars 16,00×8,00 m;
  • First deck slab formed by tiled vigor 50 cm beams and cross beams at overturns;
  • Attic roof tiles formed by TTL 50 cm and 50 cm vigor of beams and cross beams at overturns;
  • Overall height of 5.79 m for the deck slab interstorey and 6.14 m for the deck covering.

Centro Commerciale Porte di CataniaSECTIONS LOT 2A AND 2B

Lot 2B:

  • 1 elevation above ground;
  • Section pillars 70×70 cm;
  • Mesh pillars 16,00×8,00 m and 16,00×16,00 m;
  • The roof is formed by 50 cm tiles vigor of beams and cross beams at overturns;
  • Useful height to the deck covering 5.33 m.

Lot 3:

  • 1 elevation above ground;
  • Section pillars 60×60 cm;
  • Mesh pillars 16,00×7,50 m;
  • The roof is made up of 50 tiles vigor and vigor of 70 cm beams at overturns;
  • Attic to ramp formed by TT tiles 70 cm beams at overturns;
  • Useful height to the deck of coverage varies between 5.20 and 5.60 m.

Centro Commerciale Porte di CataniaSECTION LOT 3

Lot 4:

  • 1 elevation above ground;
  • Section pillars 60×60 cm;
  • Mesh pillars 16,00×7,50 m (variable);
  • The roof is made up of 50 tiles vigor and vigor of 70 cm beams at overturns;
  • Attic to ramp formed by TT tiles 70 cm beams at reverse.

FIRE RESISTANCE

LOT 1

  • R 180 for intermediate floors made with tiled vigor 50;
  • R 120 for floors roofing tiles made with TTL 50;

LOT 2A

  • R 180 for intermediate floors made with tiled vigor 70;
  • R 120 for intermediate floors made with tiled vigor 50;
  • R 120 for floors roofing tiles made with TTL 50;

LOT 2B

  • R 120 for floors roofing tiles made with vigor 50;

LOT 3

  • R 120 to cover the floors tiled vigor made with 50 and 70;

LOT 4

  • R 120 to cover the floors tiled vigor made with 50 and 70;

INTENDED USE

Inside the “Mall Porte di Catania” the ground floor and the basement of lot 1 and part of Lot 2, are home to the shopping arcade, the hypermarket and offices. The cover of the same batch is instead used for parking discovered. At the mall are located, on the north and south sides of the building, the main entrances to the center that open onto spacious distribution.
Lots 3:04 hosting instead the ground floor covered parking and first floor parking discovered, both in communication with the mall.

CLADDING WALL

They consist of horizontal panels in the AC insulated, thick 24 cm, width of 2.50 m and 16.00 m in length, with a pearly finish grit of Sicily on matrix of white concrete that form rectangular patterns made with false joints.

TIMING OF REALIZATION

Attribution of the order: October 30, 2007
Start assembling prefabricated structures: May 5, 2008
Final installation of prefabricated structures including ancillary works: April 4, 2009
Public opening of the mall: Spring 2010
